2025 Bobcat L65 HVAC Cab Comfort Package # 2332



HVAC Cab Comfort Package Included: Enclosed Cab with HVAC Front and rear wiper / washer, Dome light, Rear defrost, Automatic Ride Control, Attachment Control Device (7 pin connector), Radio Ready, Cloth suspension Seat,





Overview

With a high bucket capacity, high lift height, impressive maneuverability and swift travel speeds it’s hard to beat the material-handling capabilities of the Bobcat® L65 compact wheel loader. This durable compact wheel loader delivers the performance, versatility and premium comfort to power through tough jobs in tight spaces.

Features may include:

  • Bobcat Tier 4, turbo-charged engine delivers powerful, high-torque performance, high efficiency and convenient service
  • Articulated steering for a tight-turning radius and high maneuverability
  • High bucket capacity (7/8 cubic yard) and 10.5-foot lift height
  • Full-color, 5-inch display panel
  • Seat-mounted joystick



Engine

Engine Power 55 hp
Emissions Tier (EPA): Tier 4
Cooling Liquid

Fuel System

Fuel Type Diesel

Drivetrain

Drive System Type: 2-speed hydrostatic with Advanced Attachment Control

Wheels & Tires

Tires, Front Specification 365/70 R18
Tires, Rear Specification 365/70 R18
Tire Tread Thickness, Front 55.5 in
Tire Tread Thickness, Rear 55.5 in

Hydraulics

Hydraulic Flow Auxiliary Std Flow: 19.8 gal/min
Hydraulic Pump Pump Capacity: 19.8 gal/min

Dimensions

Length with Standard Bucket: 218 in
Width (over tires): 69.7 in | (with bucket): 74.8 in
Height Dump Angle @ Maximum: 45° | to Bucket Hinge Pin: 10.58 ft | with Operator Cab: 97.3 in
Turning Radius Inside w Bucket: 2000 mm
Outside Turning Radius 169.2 in | w Forks: 4591 mm
Wheelbase 82.7 in
Dimensions Articulation Angle: 40° | Oscillation Angle: 8° | Rollback Angle: 55°
Ground Clearance 11.3 in

Capacities

Load Capacity, Land Rated Operating Capacity with Bucket (Straight): 3,133 lb | Rated Operating Capacity with Bucket (Articulated): 2,618 lb | Rated Operating Capacity with Forks (Straight): 3,759 lb | Rated Operating Capacity with Forks (Articulated): 3,172 lb | Tipping Capacity with Bucket (Straight): 6,266 lb | Tipping Capacity with Bucket (Articulated): 5,236 lb
Cargo Capacity Bucket: 0.86- 1.3 yd3
Fuel Capacity Tank: 20.8 gal

Weights

Weight, In Running Order Operating: 9944 lb
